9.00-16 8.25-16 7.50-16 7.00-16 6.50-16 6.50-15 6.50-14 6.00-16 6.00-15 6.00-14 6.00-13 5.50-13
Features:
Suitable Conditions:
Strong tire body design fro Light truck use.
Description
Strong tire body design fro Light truck use.
Wear-resistant,anti-cracking,fast heat dissipation.
Data table
| SIZE | PR | PATTERN | TREAD DEPTH(mm) | STANDARD RIM | MAX LOAD(kg)/PRESSURE(kpa) | SECTION WIDTH(mm) | OVERALL DIA(mm) | |
| SINGLE | DUAL | |||||||
| 9.00-16 | 16 | LUG | 13 | 6.50H | 2120/730 | 1850/730 | 255 | 890 |
| 8.25-16 | 16 | LUG&RIB | 11 | 6.50H | 1800/730 | 1600/730 | 235 | 855 |
| 14 | 11 | 6.50H | 1700/630 | 1500/630 | 235 | 855 | ||
| 7.50-16 | 14 | LUG&RIB | 11/9.5/10.5 | 6.00G | 1500/730 | 1320/730 | 215 | 805 |
| 12 | 11/9.5/10.5 | 6.00G | 1400/630 | 1250/630 | 215 | 805 | ||
| 10 | 11/9.5/10.5 | 6.00G | 1250/530 | 1120/530 | 215 | 805 | ||
| 7.00-16 | 12 | LUG&RIB | 10/9.5/10 | 5.50F | 1215/630 | 1060/630 | 200 | 775 |
| 10 | 10/9.5/10 | 5.50F | 1090/530 | 950/530 | 200 | 775 | ||
| 6.50-16 | 12 | LUG&RIB | 9 | 5.50F | 1060/630 | 925/630 | 185 | 750 |
| 10 | 9 | 5.50F | 975/530 | 875/530 | 185 | 750 | ||
| 6.50-15 | 10 | RIB | 9 | 4.50E | 950/530 | 825/530 | 180 | 730 |
| 6.50-14 | 10 | RIB | 9 | 4½J | 900/530 | 800/530 | 180 | 705 |
| 6.00-16 | 10 | LUG&RIB | 10/9 | 4.50E | 850/530 | 750/530 | 170 | 730 |
| 6.00-15 | 10 | CROSS COUNTRY | 10 | 4.50E | 825/530 | 730/530 | 170 | 705 |
| 8 | RIB | 8/9 | 4.50E | 730/420 | 630/420 | 170 | 705 | |
| 6.00-14 | 8 | CROSS COUNTRY | 9.5/9 | 4½J | 690/420 | 600/420 | 170 | 680 |
| 8 | RIB | 8 | 4½J | 690/420 | 600/420 | 170 | 680 | |
| 6.00-13 | 8 | RIB & LUG | 9 | 4.50B | 650/420 | 580/420 | 170 | 655 |
| 5.50-13 | 8 | RIB | 8 | 4.00B | 560/420 | 500/420 | 160 | 620 |
