11x4.00-5 13x5.00-6 13x6.50-6 15x6.00-6 16x6.50-8 18x8.50-8 18x9.50-8
Features:
Suitable Conditions:
Lawn and Garden MoverTel: +86-532-85616527
E-mail: David@marristyre.com
Description
Data table
Size | PLY | TT/TL | Tread Depth(mm) | Rim Width(in) | SW(mm) | OD(mm) | MAX .Load(Lbs) | PSI |
11x4.00-5 | 4 | TL | 1.5 | 3.00 | 100 | 280 | 325 | 46 |
13x5.00-6 | 2 | TL | 3.0 | 3.50 | 120 | 327 | 295 | 20 |
13x5.00-6 | 4 | TL | 3.0 | 3.50 | 120 | 327 | 440 | 40 |
13x6.50-6 | 4 | TL | 3.5 | 5.00 | 162 | 340 | 460 | 28 |
15x6.00-6 | 2 | TL | 4.0 | 4.50 | 164 | 367 | 365 | 14 |
15x6.00-6 | 4 | TL | 4.0 | 4.50 | 164 | 367 | 570 | 30 |
15x6.00-6 | 6 | TL | 4.0 | 4.50 | 164 | 367 | 710 | 40 |
15x6.00-6 | 10 | TL | 4.0 | 7.50 | 164 | 367 | 1015 | 75 |
16x6.50-8 | 2 | TL | 4.0 | 5.375 | 169 | 414 | 415 | 14 |
16x6.50-8 | 4 | TL | 4.0 | 5.375 | 169 | 414 | 620 | 28 |
18x8.50-8 | 2 | TL | 4.5 | 7.00 | 217 | 451 | 515 | 10 |
18x8.50-8 | 4 | TL | 4.5 | 7.00 | 217 | 451 | 815 | 22 |
18x8.50-8 | 6 | TL | 4.5 | 7.00 | 217 | 451 | 1050 | 34 |
18x9.50-8 | 2 | TL | 3.8 | 7.00 | 217 | 174 | 695 | 12 |
18x9.50-8 | 4 | TL | 3.8 | 7.00 | 217 | 471 | 1040 | 24 |
18x9.50-8 | 6 | TL | 3.8 | 7.00 | 217 | 471 | 1320 | 36 |
