23.5R25 23.5R25 26.5R25 29.5R25 29.5R29 600/65R24 600/65R25 750/65R25 850/65R25 875/65R29 16.00R25
Features:
Suitable Conditions:
Designed to deliver exceptional comfort and for Loader, Grader, Dozer,articulated trucks.
Description
With wide and stabile tread. Exellent traction and adhesion. Designed to deliver exceptional comfort and for articulated trucks.
Data table
| 轮胎规格 Tire Size | 星级强度 Star Rating | 符合指数 Load Index | 花纹代码 Tra Code | 花纹深度 Tread Depth(mm) | 有无内胎 Type | 标准轮辋 Standard Rim (Width&Flange) | 新胎充气外缘尺寸(mm) | 最大负荷 Max.Load(kg) | 标准气压 Standard Pressure(bar) | 最高速度 Max.Speed (km/h) | |
| 外直径 Diameter | 断面宽 Section Width | ||||||||||
| 23.5R25 | ★★ | 201 | L-3 | 32 | TT | 19.50/2.5 | 1617 | 597 | 14500 | 6.5 | 10 |
| 23.5R25 | ★★ | 201/185 | L-3 /E-3 | 34 | TL | 19.50/2.5 | 1617 | 597 | 14500/9250 | 6.5/5.25 | 10/50 |
| 26.5R25 | ★★ | 209/193 | L-3 /E-3 | 37 | TL | 22.00/3.0 | 1750 | 673 | 18500/11500 | 6.5/5.25 | 10/50 |
| 29.5R25 | ★★ | 216/200 | L-3 /E-3 | 43.5 | TL | 25.00/3.5 | 1873 | 750 | 22400/14000 | 6.5/5.25 | 10/50 |
| 29.5R29 | ★★ | 218/202 | L-3 /E-3 | 44.5 | TL | 25.00/3.5 | 1975 | 750 | 23600/15000 | 6.5/5.26 | 10/50 |
| 600/65R24 | ★★ | 187/178 | L-3 /E-3 | 35.5 | TT | 19.50/2.5 | 1415 | 606 | 9750/7500 | 4.75/4.25 | 10/50 |
| 600/65R25 | ★★ | 193/180 | L-3 /E-3 | 39 | TL | 19.50/2.5 | 1480 | 640 | 11500/8000 | 4.75/4.25 | 10/50 |
| 750/65R25 | ★★ | 202/190 | L-3 /E-3 | 45 | TL | 24.00/3.0 | 1599 | 738 | 15000/10600 | 4.75/4.25 | 10/50 |
| 850/65R25 | ★★ | 207/190 | L-3 /E-3 | 49 | TL | 27.00/3.5 | 1740 | 852 | 17500/12500 | 4.75/4.25 | 10/50 |
| 875/65R29 | ★★ | 241/203 | L-3 /E-3 | 53 | TT | 28.00/3.5 | 1881 | 883 | 21200/15500 | 4.75/4.25 | 10/50 |
| 16.00R25 | ★★ | 177B | E-4 | 46 | TL | 11.25/2.0 | 1532 | 445 | 7300 | 7 | 50 |
